◇◇ Features ◇◇
AOI Function: This Appearance Detection AOI Equipment automatically proceeds Matsuba Motoko soldering cosmetic inspection, dimension inspection, coating cosmetic inspection, dimension inspection, high inspection accuracy;
Automation function: The entire production line is interconnected, enabling the connection of full process flow. Compatible with automated loading and unloading carts to dock with AGV;
High compatibility: Support template addition for different product models to set inspection parameter;
Software Function: Data query, export, and analysis functions, user-friendly interface with simple operation, MES integration capability;
Powerful AI function: This Electronic Component AOI Equipment achieves automatic defect marking and model training, false defect filtering to improve first pass rate;
High efficiency, about 6000 pcs/h.
◇◇ Specifications ◇◇
Loading and unloading docking method | Cart docks with AGV |
Overall efficiency | 6000pcs/h |
Detection items | Soldering cosmetic defects: misalignment (lateral/vertical misalignment, chip rotation), solder wetting, solder ball, solder bridging, etc. Coating Cosmetic defects: dimension verification (coating length, critical diameter), crack, chipping, protrusion, contaminant adhesion, insufficient coating. |
Downtime rate | ≤3% |
Software function | 1. Real-time inspection process and final inspection results display; 2. Production data, product batch information, yield rate statistics can be saved, queried and exported to Excel; |
Inspection ability | Detection rate 100%, overkill rate 5% |
Automation process | Including soldering, cleaning, soldering cosmetic, coating, coating hardening, coating cosmetic, resistance inspection and dock with transfer machine |
Overall size | L*W*H: 42000mm*1700mm*2000mm |
