◇◇ Features ◇◇
AOI function: This Component Detection AOI Equipment achieves high-precision inspection of chip soldering/ continuous cosmetic defects and dimension defects, cosmetic defects and dimension defects after coating;
Automation function: Full-line integration with automated material handling. Connects entire process, compatible with automatic loading and unloading carts for AGV docking;
High compatibility: Supports template creation and parameter configuration for diverse product models;
Software function: The Online AOI Equipment is equipped with the function of data query, data export and data analysis, user-friendly software interface and MES integration;
Powerful AI capability: The software automatically marks defects and proceed model training, filters false defects, and improves product yield;
High efficiency, about 3000 pcs/ h;
◇◇ Specifications ◇◇
Loading and unloading docking method | Cart docks with AGV |
Efficiency | 3000pcs/h |
Inspection item | Chip soldering cosmetic defect: short circuit, open circuit, misalignment (external), insufficient solder, cracked component, bulging (external), missing component, oxidation, misalignment (internal), bulging (internal). Continuous soldering cosmetic defect : short circuit, open circuit, insufficient clearance, cold solder joint-exposed lead, excessive solder on lead, lifted lead, excessive solder, insufficient solder-exposed conductor, solder bump, component body length measurement. Coating cosmetic defect: dimension inspection (overall coated length, coating outer diameter at joint section, coating outer diameter at the chip mounting area), cosmetic inspection (bubble, dirt, deformation, pinhole, surface scratch). |
Failure rate | ≤3% |
Software function | 1. Real-time inspection process and final inspection results; 2. It can conduct statistics on production data, batch information and yield. It also supports data saving, query, and data export to Excel; |
Inspection ability | Inspection rate: 100%, overkill rate: 5% |
Automated process | Including soldering, cleaning, soldering cosmetic inspection, coating applicator, curing furnace, coating cosmetic inspection, cartridge tip adhesive dispensing, tip curing tunnel, electrical testing and inter-station conveyors. |
Full line dimension | L*W*H: 67000mm*2000mm*2500mm |
