Laser Direct Imaging Equipment Classification and Development Trend

Table of Content [Hide]

    Principle of Laser Direct Imaging Equipment

    The principle of laser direct imaging equipment belongs to a type of direct imaging, where the light is emitted by an ultraviolet laser, mainly used in the exposure process in PCB manufacturing. The imaging quality of laser direct imaging technology is clearer compared to traditional exposure technology and has obvious advantages in mid-to-high-end PCB manufacturing. With the rapid progress in PCB design demands requiring corresponding advanced technology in the PCB production process (to achieve thinner materials, more complex structures, and finer graphic requirements within the range of micro errors), traditional contact-based template exposure developing technology can no longer meet the requirements of high-level PCB applications.


    Classification of Laser Direct Imaging Equipment

    By application area


    It can be divided into industrial laser direct imaging equipment, scientific research laser direct imaging equipment, medical imaging laser direct imaging equipment;


    By working principle


    It can be divided into optical principle laser direct imaging equipment, spectral principle laser direct imaging equipment;


    By imaging method


    It can be divided into reflective laser direct imaging equipment, absorptive laser direct imaging equipment;


    By scanning method


    It can be divided into point scanning laser direct imaging equipment, line scanning laser direct imaging equipment, surface scanning laser direct imaging equipment;


    By imaging resolution


    It can be divided into high-resolution laser direct imaging equipment, medium-resolution laser direct imaging equipment, low-resolution laser direct imaging equipment.


    Development Trend of Laser Direct Imaging Equipment

    The future growth prospects of laser direct imaging machine are broad. Technologically, precision and resolution continue to improve, the degree of intelligence and automation continues to enhance, and imaging speed accelerates. Due to technological development and the continuous expansion of applications, its market scale and technological level are consistently improving. With the continuous development of technology and the growing application demands, the laser direct imaging equipment industry will continue to develop towards technological innovation, intelligence, multi-field applications, and environmental protection, and the market has ushered in more development opportunities.
