◇◇ Overview ◇◇
It provides reliable surface pretreatment for critical processes including printing, coating, lamination, and encapsulation, while addressing common issues like poor adhesion, uneven coating, and weak bonding. Furthermore, plasma cleaning offers an eco-friendly, efficient, and controllable dry alternative to traditional solvent-based cleaning methods.
◇◇ Features ◇◇
The equipment operates under normal atmospheric pressure, eliminating the requirement for the vacuum chamber and complex vacuum pumping systems or sealed chambers.
It enables large-area uniform treatment, with the processing width typically reaching several centimeters or even over one meter. It allows for one-time processing of large-sized materials or simultaneous handling of multiple pieces, ensuring uniformity of treatment effects along the width direction.
Non-contact, dry, environmentally friendly, multi-functional treatment. It is highly efficient, fast, and easy to integrate into production line.
It can handle various polymer materials (plastics such as PP, PE, PET, PVC, PI, etc.), rubber, metals, ceramics, glass, composite materials, textiles, paper, non-woven fabrics, etc.
◇◇ Technical Specifications ◇◇
Plasma power | 2000W（Max）/20-60KHz（Option） |
Treatment height | 1mm-5mm（Max） |
Treatment width | 120mm-800mm（Option ） |
Treatment speed | 0-3m/min (adjustable according to customer's process requirement) |
Working gas | N2 +CDA |
Overall size | 550mm*150mm*120mm |
Nozzle weight | 20KG |
Power supply | 380V/AC ,50/60Hz |
◇◇ Application ◇◇
