◇◇ Features ◇◇
● Real-Time Inspection & Results Display
The software interface provides real-time monitoring of the inspection process and displays final inspection results.
● Defect Detection & Data Management
Detects and categorizes defects, displaying their precise locations.
Generates defect maps and stores complete inspection images.
● Product & Parameter Configuration
Supports new product setup and parameter adjustments.
Automatic parameter switching upon product change.
Product database capacity: >50 sets.
● Production Data Tracking & Export
Records production data, including product information, batch information, output quantities, yield statistics, defect counts, and defect rates.
Enables customizable data storage and export to Excel.
● Compatible product dimension
Length: 100–194 mm Width: 100–142 mm Thickness: ≤ 0.635 mm
● Continuous Operation
This Appearance Defect Visual Inspection Equipment supports non-stop loading and unloading for uninterrupted production.
◇◇ Technical Specifications ◇◇
Cycle time | 6s/pcs |
Power consumption | About 6KW |
Air pressure | 0.6Mpa |
Voltage | 220VAC |
Overall size | 3900mm(L)*1900mm(W)*2000mm(H) |
